operation table pads
AG-OT015 hospital surgical medical operation table pads
Introduction
Electric operating table can be operated for clinical use.
Operating table consists of two parts: mechanical and electro-hydraulic control system. Depending on manual operation, the product can meet the requirement of posture in clinical operation.
| Model | AG-OT015 |
| Size | Overall 2100 *500 *750-950mm |
Technicial Parameters | 1. Safe working load 135kg |
| 2. Dimension of table top:Overall Size 2100mm*500mm | |
| 3. Table top of from floor: Min Height. 750mm Max Heigh. 950mm Adujst.200mm | |
| 4. Head Section: 250×500mm | |
| 5. Back Section: 250×500mm | |
| 6. Shoulder Section :250×500mm | |
| 7. Seat section: 450×500mm | |
| 8. Leg Section: 600×240mm Foot Section: 180×273mm | |
| 9. Reversed Trendelenburg ≥50° | |
| 10. Trendelenburg ≥30° | |
| 11. Lateral Tilt ≥20° | |
| 12. Head Section Raised from the horizontal ≥30° | |
| 13. Head Section lowered from the horizontal ≥30° | |
| 14. Kidney Bridge Elevation≥80mm | |
| 15. Foot Rest-can be kept horizontally or perpendicularly to the Leg Section. | |
| 16. Back Section Raised from the horizontal ≥75° | |
| 17. Back Section Raised from the horizontal ≥10° | |
| 18. Leg Section Lowered from the horizontal ≥90° | |
| 21. Power :customized |
| Head Rest | 250×500mm |
| Back section | 465×500mm |
| Kidney Bridge | 75×500mm |
| Seat Section | 450×500mm |
| Leg Section | 600×240mm |
| Foot Rest | 273×180mm |
Table Top from Floor:
| Min. height | 750mm |
| Adjust | ≥200mm |
Range of Movements:
| Max. Reversed Trendelenburg | ≥15° |
| Max. Trendelenburg | ≥20° |
| Max. Lateral Tilt | ≥15° |
Adjustments of Sections:
| Head Rest-raised from the horizontal | ≥45° |
| Head Rest-lowered from the horizontal | ≥90° |
| Back Section-raised from the horizontal | ≥45° |
| Leg Section-lowered from the horizontal | ≥90° |
| Leg Section-opened | ≥90° |
| Backward and Forward movements | ≥400mm |
| Kidney Bridge Elevation | ≥100mm |
Foot Rest-can be kept horizontally or perpendicularly to the Leg Section:
| Safe working load | 135kg |
Accessory:
| Foot switch | 1 piece |
| Shoulder holder | 1 piece |
| Pillow | 1 piece |
| Arm rest | 1 piece |
| Handle | 1 piece |
| Anaesthesia screen frame | 1 pair |
| Filth basin | 1 pair |
| Leg holder | 1 pair |
| Assist platform | 1 pair |
